feat(aggregation): Add MoCo

[rkhosrowshahi]

• Linked to Aggregator tracker #665

Adds MoCo (ICLR 2023) as MoCo / MoCoWeighting with MatrixWeighting and Stateful, plus docs and tests. Keeps a moving Jacobian estimate $$Y$$ and task weights $$\lambda$$; returns $$\lambda^\top Y$$. Call reset between runs.

Tests:

• tests/unit/aggregation/test_moco.py (behavior, reset, getters/setters, edge cases, alignment with MoCoWeighting and y)
• tests/unit/aggregation/test_values.py (fixed baselines for MoCo / MoCoWeighting)

[rkhosrowshahi]

Hi @ValerianRey,
Could you please review the code and assign labels?
Thanks!

[PierreQuinton]

This should never happen (I think we can safely assume that matrix.shape[0] > 0 in the forward call to an aggregator. Maybe we want to specify that somewhere @ValerianRey

[ValerianRey]

I agree, let's get rid of this. And obviously matrices should have at least 1 row, it's not even like autojac can output jacobians with 0 rows. So it would be when a user would really want to aggregate their own empty matrix with this specific aggregator. This will not happen.

[PierreQuinton]

This is a bit weird, why not having a no_grad around the whole function instead? Also what is the current philosphy on grads of outputs of aggregators @ValerianRey ? Should we unify this?

[ValerianRey]

There are just two cases:

1. The aggregator/weighting is differentiable: and we do not want to use any torch.no_grad(), so that the graph is correctly built and stored

2. The aggregator/weighting is non-differentiable (could be for example because some operations are made on numpy arrays, like for UPGrad, DualProj, and a few others, or for some other niche reasons, like PCGrad, and I think similarly GradVac): we want to raise an error when we try to backward through it (we do that already) and I even think we would like to prevent graph construction by wrapping the forward in a torch.no_grad() (which we don't do currently). And now that I think of it, I don't even think we need to raise an error when calling backward on a non-differentiable module if its forward is wrapped in a torch.no_grad(). No graph will ever be created to begin with, so autograd will never try to backward through the module.

So I think that we should improve on that:

• Differentiable aggregators/weighting should inherit from a Differentiable mixin. It will not do anything, and it wont be public, but it will serve as internal documentation.
• Non-differentiable aggregators/weighting should inherit from a NonDifferentiable mixin (similarly protected). It could maybe wrap the forward pass in a torch.no_grad, (and maybe still make it raise an error if we try to differentiate through it).

About MoCo, idk if it's differentiable or not. I guess that changing the value of y inplace will lead to runtime error when we try to differentiate through it (the same reason why we made PCGrad non-differentiable). Need to verify that. If it's not, I think we should make it inherit NonDifferentiable. If it is, let's remove the torch.no_grad and matrix.detach. In any case, let's remove those two things because NonDifferentiable will handle it itself if we add it.

I'll ask claude to work on that.

[ValerianRey]

Fixed in #677

[PierreQuinton]

Fantastic, upon merge of #677 this should be removed, and then the aggregator/weighting pair should implement the Non differentiable mixin. @rkhosrowshahi Take a look at #677 as it specifically needs to be inherited first.

[ValerianRey]

/opencode:Plan please review this and compare this implementation to that of LibMTL (https://github.com/median-research-group/LibMTL/blob/main/LibMTL/weighting/MoCo.py)

[opencode-agent]

Based on my analysis of the TorchJD MoCo implementation and comparison with the LibMTL reference, here is my comprehensive review:

Comparison Summary

Key Differences

Aspect	TorchJD Implementation	LibMTL Reference
Gradient Normalization	❌ MISSING - Uses raw matrix directly	✅ Normalizes by grad norm and scales by loss: grads[tn]/(grads[tn].norm()+1e-8)*losses[tn]
Architecture	MoCoWeighting + MoCo aggregator classes	Single MoCo class with backward()
State Management	Stateful mixin with _state_key validation	init_param() method
Parameters	Constructor with property validation	Passed via kwargs to backward()
API	forward(matrix) returns aggregated vector	backward(losses) handles grad computation + aggregation
Empty Matrix	Explicit handling (lines 114-118)	Not handled

Critical Issue: Missing Gradient Normalization

The TorchJD implementation is missing the gradient normalization step from LibMTL. In LibMTL (line 43-44):

for tn in range(self.task_num):
    grads[tn] = grads[tn]/(grads[tn].norm()+1e-8)*losses[tn]

This normalization is critical to the MoCo algorithm as described in the paper. Without it:

1. The moving estimate y may not properly track normalized gradient directions
2. The task weight updates may be skewed by gradient magnitude differences
3. The algorithm may not converge as expected

Recommendation: Add the normalization step or document why it's omitted (if the expectation is that the input matrix is already normalized).

Review Comment Addressing

Per the existing PR reviews by @PierreQuinton and @ValerianRey:

1. Line 114-118 (empty matrix check): ✅ Agree with removal - matrices should always have ≥1 row in practice

2. Line 129-130 (torch.no_grad and detach):

   • Current: torch.no_grad() context + explicit detach() calls
   • LibMTL: Only torch.no_grad() wrapper
   • Recommendation: Follow ValerianRey's suggestion to create a NonDifferentiable mixin that wraps forward in torch.no_grad(), consistent with other non-differentiable aggregators (PCGrad, CAGrad, etc.)

Code Structure Assessment

Strengths:

• Clean separation between MoCoWeighting and MoCo aggregator
• Proper parameter validation with setters
• Good test coverage for state management and edge cases
• Proper state tracking with _state_key for device/dtype validation

Areas for Improvement:

1. Add gradient normalization to match LibMTL/paper
2. Remove empty matrix handling (lines 114-118)
3. Consider NonDifferentiable mixin instead of explicit no_grad + detach
4. Documentation should clarify if input matrix is expected to be pre-normalized

Verification Recommendation

Before merging, verify numerical equivalence with LibMTL on a simple test case to ensure the implementation produces identical outputs given the same inputs (accounting for the normalization difference).

opencode session  |  github run

[ValerianRey]

Add gradient normalization to match LibMTL/paper

Let's not do that. We will add normalization as wrappers.

[PierreQuinton]

Few things to change/clarify after review of this and the paper. Tests need a more thorough review.

[PierreQuinton]

In the paper, the softmax is supposed to be a projection to the probability simplex. Why is this a softmax (it is on the probability simplex, but not a projection)?

[PierreQuinton]

The size of matrix/y are the critical part. This is slightly costly because we have another time the full Jacobian in memory. I would not use y and use self._y instead to garbage collect the previous value and save one full Jacobian. Actualy the most memory efficient implementation would be:

Suggested change

	y = y - beta_step * (y - matrix.detach())
	self._y = (1-\beta_step) * self._y
	self._y += beta_step * matrix.detach()

With this you have exactly two Jacobians stored.

[PierreQuinton]

I think this will be complicated to adapt with the normalization wrapper as we normalize the y itself, not matrix. So I think the normalization step of equation 6 needs to be implemented here. Note that what opencode suggested above from LibMTL doesn't match what is said in the paper, so I'm not sure which one to use.

[PierreQuinton]

I think this is incorrect. In equation 10 of the paper, they use lambda @ y as an update, not lambda @ matrix. I think this would make moco not weighted (the row spans of matrix and y can be very different in general).

[PierreQuinton]

My bad, I just saw below that while this is a weighting, the moco aggregator is not weighted. I assumed wrongly that it was.

[PierreQuinton]

Is the role of this function to initialize the state if none? we call it differently if so, maybe something in the direction of _conditionally_initialize_state (but probably improvable).

[PierreQuinton]

can remove

Suggested change

	if matrix.shape[0] == 0:
	return matrix.sum(dim=0)

[PierreQuinton]

I would not do that. No reason to create a wrong differentiation graph for vector. Maybe we want to make this aggregator/weighting pair non-differentiable (because we don't want to keep all the Jacobians for all times). This can be done after #677 is merged.

Suggested change

	if matrix.requires_grad:
	vector = vector + 0.0 * matrix.sum(dim=0)

[PierreQuinton]

/opencode:Plan Can you review the tests? compare to the tests of the aggregation codebase and try to match the quality and reason about all concepts that needs to be tested.

[opencode-agent]

Based on my thorough review of the MoCo tests compared to the existing aggregation test patterns, here's my comprehensive assessment:

Test Quality Review: MoCo Implementation

Overall Assessment: Good Quality with Minor Improvements Needed

The MoCo tests are well-structured and follow most of the established patterns in the codebase. They provide good coverage of the key functionality.

---

What's Well Covered (Strengths)

Aspect	Coverage	Notes
Representation tests	✅	test_representations() follows the exact pattern used in GradVac, DualProj, etc.
State management	✅	test_reset_restores_first_step_behavior, test_weighting_reset_clears_state - excellent coverage of stateful behavior
Aggregator/Weighting alignment	✅	test_weighting_matches_aggregator_state_update verifies the relationship between MoCo and MoCoWeighting
Parameter validation	✅	Getters, setters, and rejection of negative values all tested
Non-differentiability	✅	test_non_differentiable uses the standard assertion
Structure tests	✅	test_expected_structure parametrized across typical and scaled matrices
Fixed value baselines	✅	Added to test_values.py with expected outputs

---

What's Missing (Gaps)

Pattern	Status	Recommendation
test_zero_rows_returns_zero_vector	⚠️ Should be removed	Per PR review comments by @PierreQuinton and @ValerianRey, empty matrix handling (lines 114-118 in _moco.py) should be removed. This test should be removed accordingly.
typical_matrices_2_plus_rows	❌ Missing	GradVac uses this for stateful tests since 1-row matrices don't make sense for multi-step stateful aggregators. MoCo should similarly filter.
Permutation invariance	❌ Not tested	Most aggregators test this (Mean, DualProj, UPGrad). Is MoCo permutation invariant? If yes, add test.
Reproducibility with manual seed	❌ Not tested	GradVac has test_reproducible_with_manual_seed - should MoCo have this too?

---

Test Structure Comparison

MoCo vs. GradVac (most similar - both stateful):

Test Category	GradVac	MoCo	Gap
Representation	✅	✅	None
Zero rows/columns	✅	✅	None
Reset behavior	✅	✅	None
Reproducibility (seed)	✅	❌	MoCo missing
Structure (parametrized)	✅	✅	None
Non-differentiable	✅	✅	None
Property tests (permutation, etc.)	❌	❌	Both missing (acceptable for stateful)
Weighting/aggregator alignment	✅	✅	None

MoCo vs. DualProj/UPGrad (property-based aggregators):

Property Test	DualProj	UPGrad	MoCo	Should MoCo have?
non_conflicting	✅	✅	❌	Test if applicable
permutation_invariant	✅	✅	❌	Test if applicable
linear_under_scaling	❌	✅	❌	Probably not (stateful)
strongly_stationary	✅	❌	❌	Probably not (stateful)

---

Specific Issues

1. Line 29-31 (test_zero_rows_returns_zero_vector):

   • This tests behavior that should be removed per PR review
   • Should be deleted when empty matrix handling is removed from _moco.py

2. Line 40-45 (test_reset_restores_first_step_behavior):

   • Uses typical_matrices which includes 1-row matrices
   • For stateful aggregators like GradVac, they use typical_matrices_2_plus_rows
   • MoCo should do the same (stateful aggregators need ≥2 rows to be meaningful across steps)

3. Missing edge case: No test for y getter raising RuntimeError when uninitialized (similar to weighting test on line 74-76)

---

Recommendations

High Priority:

1. Remove test_zero_rows_returns_zero_vector (matches PR review to remove lines 114-118 from implementation)
2. Change test_reset_restores_first_step_behavior to use typical_matrices_2_plus_rows instead of typical_matrices

Medium Priority:
3. Add test for aggregator's y property raising RuntimeError when uninitialized (mirror of line 74-76)
4. Consider adding test_reproducible_with_manual_seed if MoCo has any stochastic behavior
5. Investigate and test mathematical properties:

• Is MoCo permutation invariant? (Most aggregators are)
• Is MoCo non-conflicting? (Important MTL property)

Low Priority:
6. Consider consolidating parameter setter tests using parametrization (currently lines 128-177 are verbose but clear)

---

Code Quality Notes

• ✅ Good: Clear test names, consistent with codebase patterns
• ✅ Good: Proper use of fixtures and parametrization
• ✅ Good: Tests both MoCo and MoCoWeighting thoroughly
• ✅ Good: Uses assert_close from torch.testing appropriately
• ⚠️ Minor: Some tests (like setters) are verbose but readable

Summary

The MoCo tests are production-ready with only minor adjustments needed:

1. Remove the zero-rows test to align with the PR review
2. Filter out 1-row matrices from reset tests (use typical_matrices_2_plus_rows)
3. Consider adding permutation invariance test if applicable

The test quality matches or exceeds most existing aggregation tests, particularly in the area of state management testing.

opencode session  |  github run

[PierreQuinton]

From the opencode review please do:

• 1
• 3
• 4: It is not stochastic, but still it would be good to have reproducibility, so if we run it twice with the same sequence of matrices, and a reset in between, it should return the same results.

For 5, no need, the properties are not satisfied (permutation invariance could be changed to permuting the sequence of all inputs to the aggregator with the same permutation, in which case it would become permutation invariant @ValerianRey )
